Description
Description
- DESIGN/CONSTRUCTION
- Single or two stage design
- Compact in size
- Accurate regulator for gas flow
- MIG/TIG applications
- Two stage version provides extremely accurate flow rates as cylinder pressure declines
- Low surge rates _ 25 PSI preset
- Forged brass body and housing cap
- 2"" (50.8 mm) high pressure gauge
- Stem type seat mechanism
- Fabric reinforced neoprene diaphragm
- External self reseating relief valve (not designed to protect downstream equipment)
- Sintered inlet filter
- PERFORMANCE
- Maximum Inlet 3000 PSIG
- Outlet pressure _ 25 PSIG (preset), 80 PSIG on CO2
- WARNING: High gas withdrawal rates on carbon dioxide may require cylinder manifolding. Consult your gas supplier..
